GE RS-FS-9001 362A1052P004 Flow switch
GE RS-FS-9001 / 362A1052P004 Technical Specification
(Industrial Flow Switch)
Specification
|
Attribute
|
Detail
|
|---|---|
|
Part Number
|
RS-FS-9001 (GE Catalog) / 362A1052P004 (Legacy)
|
|
Manufacturer
|
General Electric (GE)
|
|
Series
|
Industrial Sensing
|
|
Country of Origin
|
USA
|
|
Function
|
Paddle-Type Flow Switch with SPDT Contact
|
Description
The GE RS-FS-9001 (362A1052P004) is a rugged mechanical flow switch for liquids in pipelines. It detects flow/no-flow conditions via a stainless-steel paddle actuator, triggering a hermetically sealed snap-action switch (SPDT). Designed for HVAC, lubrication systems, and cooling circuits (≤150 PSI). Features adjustable setpoint (0.2–10 ft/s), NEMA 4X/IP65 enclosure, and corrosion-resistant construction.
Features
- Mechanical Design:
- 316L stainless steel paddle & shaft
- Adjustable setpoint screw (calibrated in ft/s or gpm)
- Brass/Ni-plated body (NPT threaded)
- Electrical:
- SPDT snap-action switch (Form C: NO/NC/COM)
- 250V AC/DC (10A resistive, 1/3 HP motor)
- Terminal block with conduit entry (1/2″ NPT)
- Robustness:
- Hermetic sealing (stem-to-switch)
- EPDM/Viton™ seals (compatible with oils/glycols)
- Vibration/shock resistant (IEC 60068-2-6/27)
Technical Specifications
|
Parameter
|
Specification
|
|---|---|
|
Port Size
|
1/2″, 3/4″, 1″ NPT female (standard)
|
|
Pressure Rating
|
150 PSI @ 100°F (230 PSI burst)
|
|
Temp. Range
|
-20°F to +250°F (-29°C to +121°C)
|
|
Flow Range
|
0.2–10 ft/s (water) / 0.5–25 gpm (1″ line)
|
|
Switch Deadband
|
Fixed 15% of setpoint
|
|
Electrical Rating
|
10A @ 250V AC / 0.5A @ 125V DC
|
|
Contact Material
|
Silver alloy (Cd-free)
|
Product Properties
|
Property
|
Specification
|
|---|---|
|
Enclosure
|
NEMA 4X/IP65 (epoxy-coated aluminum)
|
|
Wetted Materials
|
SS316L paddle, brass body, EPDM/Viton™ seals
|
|
Weight
|
1.2 kg (2.6 lbs) – 1″ NPT version
|
|
Mounting
|
Vertical/horizontal pipeline (flow direction → paddle)
|
|
Compliance
|
UL 61010-1, CE, RoHS
|
|
Cable Entry
|
1/2″ NPT × 2 (dual entries for daisy-chaining)
|
Performance Metrics
|
Metric
|
Value
|
|---|---|
|
Repeatability
|
±2% of setpoint
|
|
Response Time
|
<1 sec (flow loss detection)
|
|
Mechanical Life
|
>5 million cycles
|
|
Electrical Life
|
100,000 cycles (@ 10A resistive)
|
|
Min. Fluid Viscosity
|
>1 cP (water-like fluids)
|
Key Applications
- HVAC Systems:
- Chiller water flow monitoring (alarm on pump failure)
- Glycol circuit protection (freeze prevention)
- Industrial Machinery:
- Lube oil flow verification (turbines/compressors)
- Coolant flow interlock (CNC machines)
- Energy Sector:
- Diesel generator jacket water flow
- Solar thermal plant fluid loops
⚠️ Critical Installation Notes:
- Paddle Orientation: MUST align with flow direction → paddle deflection WITH flow.
- Minimum Pipe Fill: Install only in fully filled pipes – air pockets cause false trips.
- Paddle Clearance: Maintain ≥2× pipe ID straight-run upstream; no elbows/valves within 5D.
- Seal Compatibility: Use Viton™ for hydrocarbons (>100°F) / EPDM for water/glycol (<250°F).
- Electrical Load: For inductive loads (e.g., pumps), use snubber circuit – contact welding risk.
- Calibration: Adjust setpoint UNDER FLOW using a clamp-on flowmeter – static calibration invalid.
- High-Temp Warning: Above 180°F, use heat-sink conduit – switch degrades at >250°F.
- Paddle Damage: Never use in slurries/solids >5% – install Y-strainer upstream.
