GE RS-FS-9001 362A1052P004 Power supply feeder protection relay
1. Product Description
The GE RS-FS-9001 362A1052P004 is a microprocessor-based, self-powered feeder protection relay designed for fused medium-voltage switchgear (typically 5-15kV). It provides comprehensive protection, monitoring, and control for electrical feeders in industrial and utility power systems. Key innovations include arc-flash reduction logic and simplified commissioning.
2. Product Series
- Series: GE Multilin RS-FS Series (Relay for Fused Switchgear).
- Family: Part of the broader GE Multilin SR (Simplified Relay) platform for streamlined protection.
3. Key Features
- Self-Powered: Operates without external power supplies (draws power from CTs).
- Arc-Flash Mitigation: Reduces arc-flash energy via instantaneous trip logic.
- Simplified Interface: Intuitive dial settings & LEDs replace complex programming.
- Compact Design: Fits ANSI switchgear compartments.
- CT/VT Integration: Direct connection to current/voltage transformers.
- Durability: Robust for harsh environments (industrial/mining).
4. Functions & Protection
- Overcurrent Protection: Phase (51/50) and Ground (51N/50N).
- Negative Sequence Overcurrent (46): Unbalance protection.
- Arc-Flash Detection: Via dedicated sensors (optional).
- Monitoring: Current, voltage, power, energy, frequency.
- Alarms & Control: 6 programmable LEDs, 4 programmable outputs.
- Breaker Failure Protection (50BF).
5. Applications & Use Cases
- Industrial Power Feeders: Manufacturing plants, data centers.
- Switchgear Protection: Metal-clad/metal-enclosed switchgear.
- Mining & Minerals: Motor feeders, conveyor belts.
- Utility Substations: Distribution feeder protection.
- Renewable Energy: Interconnection protection.
6. Technical Specifications & Parameters
Electrical Parameters
|
Parameter
|
Specification
|
|---|---|
|
Rated Voltage
|
100-240V AC/DC (auxiliary) / Self-powered via CTs
|
|
Frequency
|
50/60 Hz (±10%)
|
|
Current Inputs
|
1A or 5A (phase/ground)
|
|
Voltage Inputs
|
120/240V phase-phase (optional VT)
|
|
Overcurrent Ranges
|
0.1–25A (1A CT), 0.5–125A (5A CT)
|
|
Trip Outputs
|
2 Form-C contacts (5A @ 250V AC)
|
|
Aux. Outputs
|
4 programmable Form-C contacts
|
Mechanical & Environmental
|
Parameter
|
Specification
|
|---|---|
|
Enclosure
|
IP40 (front), ANSI Type 1
|
|
Dimensions (HxWxD)
|
177 x 140 x 144 mm (7″ x 5.5″ x 5.7″)
|
|
Weight
|
~1.8 kg (4 lbs)
|
|
Operating Temp.
|
-40°C to +70°C (-40°F to +158°F)
|
|
Certifications
|
UL 508, IEC 60255, CE
|
Communications & I/O
|
Parameter
|
Specification
|
|---|---|
|
Digital Inputs
|
4 programmable (24-250V DC)
|
|
Communication
|
RS-485 (Modbus RTU) or Ethernet (optional)
|
|
LED Indicators
|
6 programmable status LEDs + alarm/trip indicators
|
