GE SR489-P5-LO-A1 Generator protection relay
GE SR489-P5-LO-A1 Technical Specification
Specification
|
Attribute
|
Detail
|
|---|---|
|
Part Number
|
SR489-P5-LO-A1
|
|
Manufacturer
|
General Electric (GE)
|
|
Series
|
Multilin™ SR
|
|
Country of Origin
|
USA
|
|
Function
|
Generator Protection Relay (Synch. Machine)
|
Description
The GE SR489-P5-LO-A1 is an advanced generator protection relay for synchronous machines up to 600 MVA. It provides comprehensive fault detection (87G/40/46/32/51V), loss-of-field (40) protection, and breaker failure (50BF) logic. Includes synchrophasor measurement (IEEE C37.118), FlexLogic™ programmable functions, and 100% stator ground fault protection via 3rd harmonic neutral.
Features
- Core Protection Elements:
- Differential (87G), Restricted Earth Fault (64G)
- Negative Sequence (46), Reverse Power (32)
- Overexcitation (24), Field Ground (64F)
- Advanced Functions:
- Load Encroachment (-LO suffix logic)
- Breaker Failure (-P5 option)
- Sync-check (25) & Auto-synchronizer (25A)
- Monitoring & Analysis:
- Real-time phasors (ΔV/Δf/ΔØ measurements)
- Waveform capture (128 cycles @ 64 samples/cycle)
- Thermal capacity tracking (rotor/stator)
- Communications:
- Dual Ethernet (IEC 61850-8-1 GOOSE)
- RS-485 (Modbus RTU/DNP3.0)
- Front USB for EnerVista™ software
Electrical Specifications
|
Parameter
|
Specification
|
|---|---|
|
Supply Voltage
|
-A1 Suffix: 120V AC/DC (85–265V range)
|
|
Current Inputs
|
1A/5A nominal (0.1–50A continuous)
|
|
Burden
|
<0.15 VA per phase (5A)
|
|
Relay Outputs
|
8× Form-C contacts (5A @ 250V AC)
|
|
Analog Inputs
|
4× 4–20mA (rotor V/I, temp sensors)
|
|
Operating Temp
|
-40°C to +85°C (IEC 60068-2)
|
Product Properties
|
Property
|
Specification
|
|---|---|
|
Display
|
240×128 graphical LCD with tactile keypad
|
|
Enclosure
|
IP52 metal casing (19″ rack mountable)
|
|
Compliance
|
IEC 60255, IEEE C37.90, NERC PRC-027
|
|
Logic Programming
|
25+ FlexLogic™ equations
|
|
Event Records
|
1024 time-tagged events + 64 oscillography files
|
|
Dimensions
|
177 × 132 × 158 mm (7.0 × 5.2 × 6.2 in)
|
|
Weight
|
2.1 kg (4.6 lbs)
|
Performance Metrics
|
Metric
|
Value
|
|---|---|
|
Differential Trip Time
|
<15 ms (internal faults)
|
|
Measurement Accuracy
|
±0.1% V/I, ±0.01 Hz
|
|
Synchrophasor Reporting
|
30/60 frames/sec (CONFIG/FAST)
|
|
Setting Groups
|
4 (hot-switchable)
|
|
Breaker Failure Delay
|
0–10 sec (1 ms steps)
|
Key Applications
- Power Generation:
- Turbine generators (gas/steam/hydro)
- Industrial cogeneration plants
- Grid Interconnection:
- Anti-islanding (81O/U) protection
- Automatic synchronization to grid
- Critical Infrastructure:
- Data centers (N+1 backup gensets)
- Offshore platforms (DNV-GL certified)
⚠️ Critical Integration Notes:
- CT Saturation: Use TPS-class CTs for 87G – ≤5% ratio error at 20×In.
- Neutral Grounding: 3rd harmonic stator ground requires high-Z NGR (>400Ω).
- LO Logic: Configure load boundaries using R-X diagram (avoid Zone 3 miscoordination).
- Breaker Failure Scheme: Requires 52a/b contacts for initiation.
- IEC 61850 Setup: Assign unique MAC/IP before energizing (defaults cause conflicts).
- Vibration Sensitivity: Mount away from switchgear >1.5m – false trips may occur.
- Firmware Alert: ≤V4.2 has known 51V timing bug – upgrade to V4.5+.
