GE V7768-320001 Technical Specification
Specification
|
Attribute
|
Detail
|
|---|---|
|
Part Number
|
V7768-320001
|
|
Manufacturer
|
General Electric (GE)
|
|
Series
|
Ventilation Control System (VCS)
|
|
Country of Origin
|
USA
|
|
Function
|
Fan Speed Control / Damper Actuator Driver
|
Description
The GE V7768-320001 is an industrial-grade motor control module designed for HVAC and ventilation systems in power plants, factories, and large facilities. It integrates fan speed regulation and damper positioning via PID logic, optimizing airflow while reducing energy consumption. Compatible with GE’s Proficy® HMI platforms, it supports seamless integration into building management systems (BMS).
Features
- Multi-Protocol Control: Modbus RTU/TCP, BACnet/IP, and Profibus DP interfaces.
- Dual-Channel Output: Drives 3-phase motors (0.75–5.5 kW) and linear damper actuators (24V DC/AC).
- Dynamic PID Tuning: Auto-adapts to load changes with ±0.5% speed accuracy.
- Diagnostic Suite: Real-time monitoring of torque, temperature, vibration, and phase loss.
- Ruggedized Operation: Rated for -40°C to +85°C (-40°F to +185°F) and 100% humidity (non-condensing).
- Fail-Safe Modes: Defaults to pre-set speed/damper position on communication loss.
Electrical Ratings
|
Parameter
|
Specification
|
|---|---|
|
Input Voltage
|
100–240V AC ±10% / 50–60 Hz
|
|
Motor Output
|
3-phase, 0–480V AC (VFD mode)
|
|
Actuator Output
|
24V DC/AC, 2A max per channel
|
|
Control Signals
|
4–20mA analog input ×2, digital I/O ×8
|
|
Surge Protection
|
6kV (ANSI/IEEE C62.41)
|
Product Properties
|
Property
|
Specification
|
|---|---|
|
Enclosure Rating
|
IP65 (dust/water jet resistant)
|
|
Cooling Method
|
Convection + heatsink
|
|
Communication Ports
|
RJ45 Ethernet, RS-485, USB-C (configuration)
|
|
Redundancy
|
Dual-redundant input power (auto-switching)
|
|
Safety Certification
|
UL 508A, CE, IEC 61800-5-1 (SIL 2)
|
|
Dimensions
|
185 × 140 × 60 mm (7.3 × 5.5 × 2.4 in)
|
|
Weight
|
1.8 kg (4.0 lbs)
|
Performance Metrics
|
Metric
|
Value
|
|---|---|
|
Speed Response Time
|
<100ms (10–100% load step)
|
|
Control Loop Update
|
1ms (motor), 10ms (damper)
|
|
Harmonic Distortion
|
<3% THD (full load)
|
|
Standby Power
|
≤5W
|
Key Applications
- Power Plant Ventilation: Forced-draft fan control in turbine halls.
- Tunnel Airflow Management: Jet fan speed regulation (NFPA 130 compliant).
- Industrial HVAC: VFD-driven exhaust systems for chemical plants.
- Data Centers: Dynamic cooling optimization via damper arrays.
⚠️ Integration Notes:
- Requires Proficy CIMPLICITY v9.0+ for advanced tuning.
- Motor wiring must follow NEMA MG-1 standards.
- Firmware updates via USB or Ethernet (SSL-encrypted).
