GE WES5120 2340-21003 24V DC sinking input module
Product Description
The WES5120 2340-21003 is a 24V DC sinking input module designed for GE’s modular VersaMax® I/O system. It provides 16 optically isolated digital inputs for industrial automation, featuring high noise immunity and real-time diagnostics.
Product Parameters & Specifications
|
Parameter
|
Specification
|
|---|---|
|
Manufacturer/Series
|
GE Intelligent Platforms / VersaMax Series
|
|
Current Model Number
|
IC200MDL740 (Replaces legacy WES5120 2340-21003)
|
|
I/O Type
|
16x DC Inputs (Sinking)
|
|
Input Voltage Range
|
24V DC (19.2–30V DC)
|
|
Input Current
|
8 mA per point (typ.)
|
|
Logic “1” Threshold
|
≥ 15V DC
|
|
Logic “0” Threshold
|
≤ 5V DC
|
|
Isolation
|
500V AC (field-to-logic)
|
|
Response Time
|
ON Delay: ≤ 1 ms
OFF Delay: ≤ 1 ms |
|
Backplane Current
|
5V DC: 55 mA
24V DC: 16 mA |
|
Connection
|
Removable screw terminal (IC200TBE002)
|
|
Operating Temperature
|
-40°C to +70°C
|
|
Safety/Certifications
|
UL 508, CE, cULus, RoHS, IEC 61131-2
|
|
Compatible Racks
|
VersaMax Micro/Nano/Standalone (e.g., IC200CHS023)
|
Key Features
- High-Density Design: 16 inputs in single-slot 30mm module.
- Diagnostic LEDs: Per-channel status (green = ON, red = fault).
- Overvoltage Protection: 50V continuous / 60V transient.
- Hot Swappable: Supports live module replacement.
- Wide Voltage Tolerance: Operates down to 19.2V DC.
Function & Role
- Sensor Interface: Connects proximity switches, push buttons, limit switches.
- Machine State Monitoring: Detects equipment status for PLC logic.
- Safety Interlocking: Non-safety rated but used in safety circuits with relays.
Applications & Industries
|
Industry
|
Use Cases
|
|---|---|
|
Automotive
|
Robotic workcell sensor monitoring, conveyor jam detection
|
|
Packaging
|
Bottle/can presence sensing, fill-level detection
|
|
HVAC Systems
|
Airflow switch monitoring, filter clog indicators
|
|
Material Handling
|
Pallet position verification, hopper level switches
|
|
Water Treatment
|
Pump run-status feedback, valve position confirmation
|
Compatibility & Integration
|
System Component
|
Compatible Models
|
|---|---|
|
Controllers
|
VersaMax Micro PLCs (IC200CPUxx), PACSystems RX3i (via IC200GBI001 adapter)
|
|
Communication
|
Supports Genius Bus, Profibus-DP, Ethernet/IP (via VersaMax comm modules)
|
|
Software
|
Proficy Machine Edition, Logic Developer PLC
|
Wiring Configuration
SINKING INPUTS:
FIELD DEVICE (+) → IN0–IN15
FIELD DEVICE (-) → COM (0V)
Critical Notes
- Polarity: Strictly sinking-only – external 24V DC supply must connect (+) to field devices.
- Derating: No derating required within full temp range (-40°C to +70°C).
- Safety Limitation: Not SIL-rated – use with safety relays for emergency circuits.
- Legacy Support: Compatible with GE Series 90-30 PLCs via adapters.
