H201TI | GE Electric Tin plated copper terminal block
Product Description
The GE H201TI is a tin-plated copper terminal block designed for secure, low-resistance electrical connections in GE (now Emerson) PLC and I/O systems. It provides reliable point-to-point wiring for signal/power distribution, featuring corrosion-resistant plating and compact design for high-density industrial panels.
Product Parameters & Specifications
|
Category
|
Specification
|
|---|---|
|
Model
|
H201TI
|
|
Manufacturer
|
GE / Emerson Industrial Automation
|
|
Series
|
VersaMax / Series 90 / RX3i Terminal Blocks
|
|
Contact Material
|
Copper alloy with tin plating (TI)
|
|
Wire Range
|
12–24 AWG (2.5–0.2 mm²)
|
|
Voltage Rating
|
300V AC/DC
|
|
Current Rating
|
10A @ 60°C
|
|
Dielectric Strength
|
2500V AC (1 min)
|
|
Contact Resistance
|
≤2 mΩ
|
|
Temperature Range
|
-40°C to +105°C
|
|
Mounting
|
DIN rail (TS35/7.5/15)
|
|
Isolation
|
Basic insulation (500V)
|
|
Certifications
|
UL 1059, CSA, CE
|
Key Features
- Corrosion Resistance: Tin plating (TI suffix) prevents oxidation in humid/chemical environments.
- High Conductivity: Low-contact resistance (<2mΩ) ensures stable signal/power transmission.
- Compact Design: 5.0mm pitch for space-efficient panel layouts.
- Secure Clamping: Screw terminals with cage clamps prevent wire slippage.
- Universal Compatibility: Fits GE VersaMax (IC200/IC600), Series 90-30, and RX3i systems.
- Visual Identification: Transparent housing for quick wire inspection.
Function & Purpose
Provides modular, insulated connection points for field wiring to PLC I/O modules, power supplies, and sensors while maintaining signal integrity and electrical safety.
Applications
- PLC Wiring: Interconnecting I/O modules, CPUs, and peripherals.
- Sensor/Actuator Integration: Connecting switches, transmitters, valves, and relays.
- Power Distribution: Branch circuits for 24V DC control systems.
- Signal Conditioning: Grounding/shield termination for analog devices.
Application Fields
- Factory Automation Control Panels
- Process Industry Junction Boxes
- Power Generation Systems
- Machinery Safety Circuits
- Transportation Infrastructure (Rail/Conveyors)
