IC697VDD100 | GE Electric Video Display Driver module
Product Function
The IC697VDD100 is an intelligent Video Display Driver module designed for GE’s Series 90-70 PLC systems. Its primary function is to generate a standard VGA output signal, enabling direct connection of a VGA monitor to the PLC rack. This allows real-time display of process data, system diagnostics, ladder logic, alarms, and operational parameters at the machine location, eliminating the need for a separate HMI or PC for basic monitoring and troubleshooting.
Product Specifications & Parameters
|
Category
|
Specification
|
|---|---|
|
Manufacturer
|
GE Fanuc / GE Intelligent Platforms (Now part of Emerson)
|
|
Series
|
Series 90-70 Programmable Logic Controller (PLC)
|
|
Module Type
|
Video Display Driver (Intelligent Option Module – IOM)
|
|
Compatibility
|
Requires installation in a VersaMax Interface Module (VIM) slot (e.g., VIM01)
|
|
Video Output
|
15-pin VGA (HD-DB15) connector
|
|
Supported Resolutions
|
640×480 (VGA), 800×600 (SVGA), 1024×768 (XGA)
|
|
Refresh Rate
|
60Hz, 72Hz, 75Hz (monitor-dependent)
|
|
Backplane Power
|
+5V DC via Series 90-70 backplane
|
|
Communication Bus
|
VIM/VME bus
|
|
Operating Temp.
|
0°C to 60°C (32°F to 140°F)
|
|
Dimensions
|
Standard double-width Series 90-70 module
|
|
Status Indicators
|
Power/Status LEDs
|
|
Software Tools
|
Logicmaster 90-70, Proficy Machine Edition (PME)
|
Series Information
Part of the GE Fanuc Series 90-70 PLC family, a high-performance, modular platform for complex industrial automation. Designed for seamless integration with VersaMax I/O modules and VIM interfaces.
Key Features
- Localized Visualization: Direct VGA output for real-time process monitoring.
- Diagnostic Hub: Displays PLC status, I/O errors, module health, and alarm logs.
- Ladder Logic Preview: Allows on-screen viewing of control logic (software-dependent).
- Plug-and-Play: Integrates into Series 90-70 racks via VIM slots.
- Operator Interface: Enables parameter adjustments and system control via connected keyboard/mouse.
Role & Purpose
- Operator Interface: Provides immediate access to process variables and alarms.
- Maintenance Tool: Accelerates troubleshooting by localizing diagnostics.
- Commissioning Aid: Facilitates PLC programming and testing during deployment.
- Cost Efficiency: Reduces reliance on external HMIs for basic operations.
Applications & Use Cases
|
Industry
|
Application
|
|---|---|
|
Manufacturing
|
Assembly line monitoring, robotic cell diagnostics, production counters.
|
|
Process Control
|
Chemical/petrochemical plant parameter display (pressure, temperature, flow).
|
|
Power Generation
|
Turbine control status, grid stability data visualization.
|
|
Water Treatment
|
Pump/valve status, tank levels, filtration alerts.
|
|
Material Handling
|
Conveyor system tracking, palletizer operations, sortation logic.
|
|
Packaging
|
Machine speed optimization, batch error reporting.
|
