IS200JPDMG1ACC S1AT005 | GE Electric Generator contact monitor input module

$899.00

In stock

💥Name: Module/Controller/Touchpad/Driver/Load cell

Model: IS200JPDMG1ACC

🚚Delivery time: goods in stock

3️⃣6️⃣5️⃣Warranty: 12 months

Shipping fee: Shipping fee: Please contact customer service.

📦Product packaging: The seller provides complete packaging

🌐Customs clearance fee: not included

☎️Phone/WeChat:15359021002

📧Email: LuckyXiao.909@Gmail.com

📲WhatsApp+86 15359021002

 🆔Skype:+86 15359021002

❤️Other websites: www.szcxgk.com

(Note: The actual price is subject to the quotation.)

IS200JPDMG1ACC S1AT005 | GE Electric Generator contact monitor input module

Product Description:

The IS200JPDMG1ACC S1AT005 is a Generator Contact Monitor Input Module designed by GE for its Mark VIe series Speedtronic turbine control systems. Its primary function is to monitor the status of critical generator contacts (such as generator circuit breaker auxiliary contacts, field breaker status, or synchronizing check relays) and provide this essential state information (Open/Closed) as high-integrity digital inputs to the Mark VIe controller. This input is vital for the control system to execute protective sequencing, initiate safety shutdowns, and manage synchronization operations reliably and safely.

Product Parameters / Specifications:

Parameter Category
Specification
Notes
Manufacturer
GE (General Electric)

Series
Mark VIe Family (Speedtronic Turbine Controls)
Part of the EX2100/Mark VIe platform
Module Type
Generator Contact Monitor Input Module
Digital Input Module for critical signals
Part Number
IS200JPDMG1ACC
Base Part Number
Revision / Variant
S1AT005
Specific hardware revision/batch code
Primary Function
Monitor status of Generator Main & Field Breakers
Detects Open/Closed state
Input Type
High Integrity Digital Input
Designed for critical safety signals
Input Channels
Typically 2 channels per module
Monitors Main Breaker & Field Breaker
Input Voltage Sensing
Designed for Dry Contact Status (e.g., 48-125 VDC)
Isolates & reads auxiliary contact state
Isolation
High Voltage Isolation (Channel-to-Channel & Channel-to-Logic)
Essential for safety and noise immunity
Mounting
VME-type Card (DIN Rail Mountable via Carrier)
Installs in Mark VIe I/O Pack
Compatibility
Mark VIe Controllers (e.g., EX2100e)
Interfaces via backplane
Communications
Via Mark VIe I/O Pack Backplane (VME)
To controller (e.g., EX2100e)
Diagnostics
On-board Diagnostics & Status LEDs
Module health, channel status
Safety Role
Critical Input for Turbine Protection (Turbine Shutdown)
Triggers protective actions on contact state change

Series: This module belongs to GE’s Mark VIe family of turbine and process control systems. It is specifically designed for use within the Mark VIe platform’s I/O architecture.

Key Features:

  • Critical State Monitoring: Dedicated to monitoring the vital Open/Closed status of generator main and field breaker auxiliary contacts.
  • High Integrity Design: Engineered for reliability and safety-critical applications within turbine control.
  • Electrical Isolation: Provides high voltage isolation between input channels and between inputs and the logic circuitry.
  • Diagnostic Capabilities: Includes on-board diagnostics and LED indicators for fault detection and channel status.
  • DIN Rail Mountable (via Carrier): Modules typically plug into a carrier board that mounts on standard DIN rails within the Mark VIe I/O Pack enclosure.
  • Designed for Harsh Environments: Built to withstand typical industrial power generation conditions (temperature, vibration, EMI).
  • Backplane Communication: Integrates seamlessly with the Mark VIe controller via the VME-style backplane.

Function/Role: The core function of the IS200JPDMG1ACC module is to acquire the high-integrity status signals (Open/Closed) from critical generator contacts and transmit this status reliably to the Mark VIe controller. It acts as the critical sensory input point for the control system regarding the generator’s main power connection and field circuit status.

Purpose/Use: This module is essential for protecting the turbine generator set. By providing accurate and reliable breaker status, it enables the Mark VIe control system to:

  1. Initiate Protective Shutdowns: Trigger a turbine trip if critical breakers open unexpectedly during operation (e.g., generator lockout).
  2. Manage Synchronization: Confirm the generator breaker is open before initiating the synchronization sequence and verify closure upon synchronization.
  3. Control Sequencing: Enable or inhibit specific control sequences (like excitation application) based on breaker states.
  4. Provide Operational Status: Display accurate breaker status to operators on control system HMIs.

Application Fields / Industries:

  • Power Generation (Primary Domain):
    • Gas Turbine Power Plants
    • Steam Turbine Power Plants
    • Combined Cycle Power Plants (CCPP)
  • Industrial Energy: Plants utilizing large GE turbine-generators for on-site power/cogeneration.
  • Marine Propulsion: Ships using GE gas turbines for propulsion (where Mark VIe controls are applied).
  • Oil & Gas: Pipeline compression stations using turbine drives controlled by Mark VIe systems.
  • Heavy Industry: Facilities with large mechanical drives powered by turbines under Mark VIe control.
  • Research & Test Facilities: Testing turbines and generators utilizing GE control systems.
