IS200VCCCH1D | GE Electric 6-slot VME backboard chassis
Product Function
The IS200VCCCH1D is a 6-slot VME backplane chassis designed for GE’s Mark VIe turbine control systems. It provides power distribution, cooling, and high-speed communication infrastructure for redundant controller modules (e.g., IS420UCSBH1A) and I/O packs, enabling robust industrial-grade control of critical turbomachinery.
Product Specifications & Parameters
|
Category
|
Specification
|
|---|---|
|
Manufacturer
|
GE Digital (GE Power Conversion)
|
|
Series
|
Mark VIe Turbine Control System
|
|
Type
|
VME Backplane Chassis
|
|
Form Factor
|
6U VME Standard (233mm x 160mm per slot)
|
|
Slot Capacity
|
6 slots (supports controllers, I/O, power modules)
|
|
Backplane Speed
|
VME64x (80 MB/s data transfer)
|
|
Power Input
|
120V AC or 125V DC (via external PSU)
|
|
Slot Voltage
|
+5V DC ±1% (max 200W total)
|
|
Cooling System
|
2x redundant axial fans (hot-swappable)
|
|
Airflow
|
25 CFM @ 0.25 in-H₂O static pressure
|
|
Operating Temp.
|
-40°C to +70°C
|
|
Relative Humidity
|
5–95% non-condensing
|
|
Weight
|
3.2 kg (empty) / 8.5 kg (fully loaded)
|
|
Certifications
|
CE, RoHS, UL, IEEE 1613 (power substations)
|
Series Information
Core component of GE’s Mark VIe Control System – compatible with:
- Controllers: IS420UCSxH1x, IS200ERxH1x
- I/O Modules: IS420PDIAH1A (Analog), IS200ESELH1B (Discrete)
- Power Supplies: IS420EPDMG3A, IS200EPSMG1A
- Chassis Options: IS200VCCCx (expansions), IS200VCRCH1B (rack mount)
Key Features
- Hot-Swap Support: Modules replaceable without system shutdown.
- Redundant Architecture: Dual-fan cooling & dual-power input capability.
- EMI Shielding: Conductive gaskets for noise immunity (IEEE 1613 Class 2).
- Live Monitoring: Slot-level voltage/current sensors with fault reporting.
- Vibration Resistance: Up to 5g operational (tested per IEC 60068-2-6).
- Optical Isolation: Fiber-optic SER ports for noise-free controller linking.
Role & Purpose
- Central Hub: Interconnects controllers, I/O, and networks in turbine control racks.
- Power Management: Distributes filtered DC power with overload protection.
- Thermal Regulation: Maintains operating temp. via forced-air cooling.
- Data Highway: Enables peer-to-peer communication between controllers via backplane.
Applications & Use Cases
|
Industry
|
Application
|
|---|---|
|
Power Plants
|
Gas/steam turbine control cabinets, excitation systems
|
|
Oil & Gas
|
Compressor station control racks, pipeline SCADA integration
|
|
Hydroelectric
|
Governor control systems, hydro turbine protection
|
|
Marine
|
Shipboard turbine control rooms, propulsion management
|
|
Industrial Drives
|
High-power motor control centers (MCCs), rolling mill automation
|
|
Renewable Energy
|
Grid synchronization systems for wind/solar farms
|
Technical Notes
- 🛠️ Configuration:
- Slot 1-2: Controller modules (e.g., IS420UCSBH1A)
- Slot 3-5: I/O packs (e.g., IS420PDIAH1A)
- Slot 6: Power module (e.g., IS420EPDMG3A)
- 🔌 Wiring:
- TB1/TB2: Field wiring terminals (removable)
- P1/P2: Fiber-optic SER links for rack-to-rack comms
- ⚡ Power Safety:
- Overcurrent trip at 120% rated load
- Ground-fault monitoring (>5mA)
- 📶 Status Indicators:
- Green LED: Healthy voltage per slot
- Amber LED: Fan/Power warning
- Red LED: Critical failure (e.g., overtemp)
Integration Rules:
- Max. 4 chassis per SER fiber loop (≤100m distance).
- Requires GE’s ToolboxST™ for backplane diagnostics.
- Annual maintenance: Fan cleaning, contact reseating.
System Integration Example
Typical Mark VIe Control Rack:
[IS200VCCCH1D Chassis]
├─ Slot 1: IS420UCSAH1A (Primary Controller)
├─ Slot 2: IS420UCSBH1A (Redundant Controller)
├─ Slot 3: IS420PDIAH1A (Analog Input)
├─ Slot 4: IS420ESWBH3A (Discrete Output)
├─ Slot 5: IS420EPDMG3A (Power Supply)
└─ Slot 6: IS420ETCGH1A (Comm. Gateway)
