IS420PPNGH1A | GE Electric Profinet I/O Controller Module
Product Description
The IS420PPNGH1A is a Profinet I/O Controller Module from GE’s Mark VIe Speedtronic series. It provides high-speed deterministic communication between Mark VIe controllers and Profinet field devices (I/O modules, drives, sensors) for real-time automation control in industrial networks.
Product Parameters / Specifications
|
Parameter Category
|
Specification
|
|---|---|
|
Manufacturer
|
|
|
Series
|
Mark VIe Speedtronic Turbine Control System
|
|
Module Type
|
Profinet IO Controller (IRT Capable)
|
|
Part Number
|
IS420PPNGH1A (
H1A = Hardware Revision) |
|
Primary Function
|
Real-time industrial Ethernet control for Profinet devices
|
|
Communication Protocol
|
Profinet IO Class 1/Class 3 (IRT)
|
|
Ports
|
2x RJ45 (10/100/1000 Mbps) + 1x SFP (1 Gbps fiber)
|
|
Data Transfer Rate
|
Up to 1 Gbps
|
|
Cycle Time
|
≤ 1 ms (IRT mode)
|
|
Max Nodes Supported
|
256 devices
|
|
Synchronization Accuracy
|
< 1 μs (with IEEE 1588 PTPv2)
|
|
Diagnostics
|
Dual-channel ring redundancy, SNMP, LLDP, Port Mirroring
|
|
Power Supply
|
24V DC (±10%) via Mark VIe backplane; 12W max
|
|
Operating Temperature
|
-40°C to +70°C
|
|
Certifications
|
UL 508, CE, IEC 61850-3, PROFINET Conformance Class B
|
Series
Part of GE’s Mark VIe Speedtronic platform for critical industrial automation.
Key Features
- Deterministic IRT Support: Hardware-based Isochronous Real-Time (IRT) for motion/time-critical control.
- Dual-Network Redundancy: MRP/MRP-Ring support (< 200ms failover).
- Secure Integration: VLAN segmentation, HTTPS/SSH encryption, and role-based access control.
- OPC UA Tunneling: Seamless data routing to enterprise systems.
- ToolboxST™ Integration: Automatic device discovery and topology mapping.
- Industrial Ruggedness: Conformal-coated PCB (humidity/dust resistance) and 15g vibration tolerance.
Function/Role
- Acts as Profinet Controller for Mark VIe systems:
- Synchronizes I/O data exchange with drives/valves/sensors.
- Manages deterministic control loops (e.g., turbine governor commands).
- Bridges Profinet networks to Mark VIe’s core Ethernet backbone.
Purpose/Use
- High-Speed Machine Control: Precision motion synchronization (≤1ms cycles).
- Process Data Acquisition: Real-time collection from distributed I/O stations.
- Safety System Integration: Interfaces with PROFIsafe devices (SIL 3).
- Legacy Migration: Replaces hardwired systems with Ethernet-APL instruments.
Application Fields
- Power Generation:
- Gas turbine fuel valve control
- Hydroelectric governor synchronization
- Wind turbine pitch/yaw systems
- Automotive Manufacturing:
- Robotic assembly line control
- Paint shop conveyor synchronization
- Pharmaceuticals:
- Fill-finish machine precision dosing
- Cleanroom environmental monitoring
- Oil & Gas:
- FPSO crane motion control
- Subsea valve actuation systems
- Water Management:
- Floodgate positioning systems
- High-speed pump VFD control
- Aerospace:
- Test rig dynamometer control
- Composites curing oven automation
The IS420PPNGH1A delivers sub-millisecond industrial control for GE’s Mark VIe, enabling microsecond-synchronized operations in safety-critical applications like turbine governing and high-speed manufacturing. Its IRT capability meets PROFINET Class 3 standards for the most demanding motion control tasks.
