Introduction to WOODWARD 9907-1183
9907-1183 Product Overview
The WOODWARD 9907-1183 is a dedicated safety logic control module, serving as a critical protection component in the brand’s 505 series turbine control systems. It specializes in real-time fault monitoring and emergency interlock control, integrating high-speed signal processing circuits and redundant logic units to ensure reliable shutdown or load reduction when abnormal conditions occur. Widely applied in thermal power plants, petrochemical refineries, and offshore turbine systems, it monitors key parameters like turbine vibration, bearing temperature, and oil pressure, triggering immediate protective actions to prevent equipment damage. Its rugged design features a double-layer metal housing with EMI shielding, adapting to high-vibration and electromagnetic interference environments. Fully compatible with WOODWARD 505E controllers and ProTech protection systems, it supports Modbus and Ethernet communication for seamless integration into DCS networks, enabling operators to track fault logs and safety events remotely.
9907-1183 Technical Specifications
-
Product Type: Safety logic control module (505 series turbine protection variant)
-
Core Functions: Multi-parameter fault monitoring, emergency shutdown interlock, safety logic execution, event logging
-
Application Compatibility: Steam/gas turbines, turbogenerators, industrial compressors, offshore propulsion systems
-
Input Configuration: 24 discrete safety inputs; 8 analog input channels (4-20mA) for critical parameter monitoring
-
Output Configuration: 16 relay outputs (5A/250V AC) for shutdown signals; 4 analog output channels for status feedback
-
Control Performance: Fault response time <10ms; logic execution accuracy 100%; supports 2oo3 voting logic
-
User Interface: 4-line LCD display for fault codes; 6 function keys for parameter setting and fault reset
-
Communication Interface: RS-485 (Modbus RTU); optional Ethernet (PROFINET); dedicated safety communication port
-
Power Supply: 24V DC nominal; 18-36V DC wide input range; redundant power input support
-
Operating Environment: Temperature -20°C to +70°C; humidity 0-95% (non-condensing); vibration resistance 10g (5-2000Hz)
-
Physical Traits: 305mm×220mm×85mm (L×W×H); weight ~3.2kg; DIN rail mount; IP54 protection rating
-
Certifications: SIL 2 certified; CE, UL, ATEX approved; complies with IEC 61508 safety standards
Recommended WOODWARD Related Models
-
WOODWARD 505E: Advanced turbine controller that coordinates with the safety module for comprehensive system management.
-
WOODWARD ProTech TPS: Turbine overspeed protection system that works with the module to enhance safety redundancy.
-
WOODWARD 9907-164: 505 series speed governor that receives interlock signals from the safety control module.
-
WOODWARD Varistroke-DX: Electro-hydraulic actuator that executes emergency shutdown commands from the module.
-
WOODWARD 2301A: Cost-effective speed governor that pairs with the module for small generator set protection.
-
WOODWARD Flex500: Multi-turbine control system that centralizes safety data from multiple 9907-1183 modules.
-
WOODWARD LinkNet-HT: Distributed I/O module that expands the module’s fault monitoring range.
-
WOODWARD 8237-1597: Digital signal regulator that provides precise parameter signals for the safety module.
-
WOODWARD APECS® 4500: Engine control module that integrates safety interlock logic from the 9907-1183.
-
WOODWARD 5009 TMR: Triple-redundant controller that uses the module’s signals for critical nuclear turbine safety.
-
WOODWARD 1712 EPG: All-in-one governing system that incorporates basic safety functions similar to the module.
-
WOODWARD K-Series Actuators: Electric throttle units that respond to emergency control signals from the module.
-
WOODWARD CPC-II: Current-pressure converter that translates the module’s signals to hydraulic shutdown valves.
-
WOODWARD 9907-167: Low-temperature turbine controller that pairs with the module for polar application safety.
-
WOODWARD 8200-1312: Digital speed control module that coordinates with the safety module for speed-related protection.
