Introduction to WOODWARD 9907-1200
9907-1200 Product Overview
The WOODWARD 9907-1200, widely recognized as the CPC-II (Current-Pressure Converter II), is a high-performance electro-hydraulic interface module engineered for industrial turbine and hydraulic control systems. As a critical bridge between electronic controllers and hydraulic actuators, it specializes in converting standard 4-20mA current signals into proportional, stable pressure outputs—directly driving steam/gas turbine valves, pipeline control valves, and servo systems to ensure precise regulation. This module is a trusted replacement for legacy models like 9907-1105 and 9907-1100, widely deployed in power plants (for generator frequency stabilization), oil & gas pipelines (for valve control), and marine propulsion systems. Its rugged IP67-rated housing resists oil contamination (complying with ISO 20/16 standards) and extreme temperatures, while a 100,000-hour MTBF ensures long-term reliability. Fully compatible with WOODWARD 505/505E governors, it supports diverse communication interfaces for seamless integration into DCS platforms, enabling remote monitoring and calibration.
9907-1200 Technical Specifications
-
Product Type: CPC-II current-pressure converter (electro-hydraulic interface module)
-
Core Functions: 4-20mA current to pressure signal conversion, proportional pressure output, turbine valve control
-
Application Compatibility: WOODWARD 505/505E governors, steam/gas turbines, turbogenerators, oil pipeline valves
-
Input Configuration: 4-20mA current control signal; 18-32VDC power input
-
Output Configuration: Proportional pressure output; 0-10VDC status feedback; max 10A output current
-
Control Performance: Conversion accuracy ±0.1%; response speed (speed loop bandwidth) up to 100Hz
-
User Interface: Integrated pressure gauge for on-site monitoring; standardized terminal blocks for wiring
-
Communication Interface: RS232, RS485, Ethernet, USB (for configuration and status transmission)
-
Power Supply: 18-32VDC wide input range; 24VDC nominal
-
Operating Environment: Temperature -40°C to +85°C; humidity 0-95% (non-condensing); IP67 protection rating
-
Physical Traits: 155mm×80mm×225mm (L×W×H); weight ~25kg; flange mounting design
-
Certifications: Compliant with industrial control safety standards; compatible with IEC specifications
Recommended WOODWARD Related Models
-
WOODWARD 505E: Advanced turbine governor that provides precise 4-20mA control signals for the 9907-1200.
-
WOODWARD 9907-164: 505 series control module that coordinates with the converter for turbine speed regulation.
-
WOODWARD Varistroke-DX: Electro-hydraulic actuator that receives pressure signals to drive turbine valves.
-
WOODWARD ProTech TPS: Turbine protection system that triggers the converter for emergency valve shutdown.
-
WOODWARD 2301A: Cost-effective governor that pairs with the converter for small turbogenerator control.
-
WOODWARD 8237-1597: Digital signal regulator that optimizes current inputs for the converter.
-
WOODWARD Flex500: Multi-turbine control system that centralizes the converter’s status data.
-
WOODWARD APECS® 4500: Engine controller that integrates the converter for CHP system valve control.
-
WOODWARD DPG 2200: Generator paralleling controller that uses the converter’s signals to balance load.
-
WOODWARD K-Series Actuators: Electric throttle units that complement the converter in multi-loop systems.
-
WOODWARD 1712 EPG: All-in-one governor with built-in signal conversion similar to the 9907-1200.
-
WOODWARD 5009 TMR: Triple-redundant controller that monitors the converter’s output for critical safety.
-
WOODWARD LinkNet-HT: Distributed I/O module that transmits the converter’s data to central DCS.
-
WOODWARD 9907-167: Low-temperature turbine controller that pairs with the converter for polar applications.
-
WOODWARD 8200-1312: Digital speed module that sends calibrated current signals to the converter.
