Introduction to ABB 5SHX1445H0001 3BHL000391P0101
Product Overview
The ABB 5SHX1445H0001 (order code: 3BHL000391P0101) is a high-voltage Integrated Gate-Commutated Thyristor (IGCT) module, specifically designed for ABB’s high-power frequency converter systems and industrial power electronic applications. As a core power conversion component, it combines the high current-carrying capacity of traditional thyristors with fast switching performance, enabling efficient AC-DC-AC conversion in high-voltage scenarios. Widely deployed in large-scale industrial drives (such as cement mill motors, steel rolling mill drives), power plant auxiliary systems, and renewable energy grid-connected converters, it reduces energy loss by up to 12% compared to conventional modules and ensures stable operation under fluctuating load conditions. Equipped with integrated gate driving and over-temperature protection, it avoids damage from abnormal electrical and thermal stresses. Its modular packaging supports parallel operation for higher power requirements, seamlessly integrating with ABB’s AC 800M control system to realize real-time monitoring and fault diagnosis of power conversion processes.
Technical Specifications
-
Product Model: 5SHX1445H0001 (Order Code: 3BHL000391P0101)
-
Product Type: High-voltage IGCT (Integrated Gate-Commutated Thyristor) module
-
Series Affiliation: ABB 5SHX High-Power Semiconductor Series
-
Core Functions: High-voltage power conversion, AC-DC-AC inversion, overcurrent protection, temperature monitoring
-
Electrical Ratings: Rated voltage 4500V; Rated current 1400A; On-state voltage drop ≤2.8V
-
Switching Performance: Turn-on time ≤2μs; Turn-off time ≤2μs; Maximum switching frequency 500Hz
-
Gate Characteristics: Gate drive voltage ±15V; Peak gate current 800A
-
Thermal Performance: Maximum junction temperature 125°C; Thermal resistance (junction-case) 0.015°C/W
-
Protection Features: Overcurrent protection, short-circuit tolerance, over-temperature shutdown, voltage surge suppression
-
Mounting Type: Bolt-on heat sink mount; Compression force 15kN (recommended)
-
Power Supply for Driver: 24VDC ±10%; Driver power consumption ≤30W
-
Operating Environment: Temperature -40°C to +85°C; Humidity 5-95% (non-condensing); IP20 (when installed in cabinet)
-
Mechanical Dimensions: 280mm×180mm×60mm (L×W×H); Weight ~4.2kg; LED status indicator
-
Certifications: CE, UL, ROHS certified; Compliant with IEC 60747-17 power semiconductor standards
