Introduction to ABB DSQC679 3HAC028357-001

DSQC679 3HAC028357-001 Product Overview

The ABB DSQC679 3HAC028357-001 is an advanced FlexPendant teach pendant specifically designed for ABB’s IRC5 industrial robot control system. As a critical human-machine interface (HMI) component, it enables operators to seamlessly program, manually control, configure parameters, diagnose faults, and monitor the robot system. Equipped with an intuitive graphical LCD touch interface and ergonomic design, the teach pendant ensures comfortable operation even during extended work sessions, significantly enhancing operational efficiency and reducing the risk of errors. It features integrated high-level safety functions, including an easily accessible emergency stop button and a three-position enabling device, providing dual protection for operators and equipment during teaching and manual operations.

DSQC679 3HAC028357-001 Technical Specifications

• Product Model: DSQC679 3HAC028357-001
• Product Type: FlexPendant Teach Pendant (for IRC5 Robot Control System)
• Core Functions: Robot programming (graphical & script-based), manual jog teaching, real-time status monitoring, parameter configuration, fault diagnosis, emergency stop control, multi-user profile management
• Power Supply: 24 V DC ±20% input; Maximum small signal input current: 5 mA; Maximum large signal input current: 0.5 A
• Display & Operation: Large-size color LCD touch screen; High-resolution display for clear presentation of program code and system information; Multi-language support; Ergonomic key layout with comfortable grip
• I/O Configuration: 24 I/O points (16 digital inputs, 16 digital outputs); Input types: Single-ended and differential; Output type: Relay; Output frequency: 100 Hz
• Communication Interfaces: Supports Ethernet and USB interfaces; Compatible with 3HAC031683-001 10m pendant cable for reliable data transmission with IRC5 controller
• Performance Indicators: Signal processing speed: 550 μs; Program capacity: 300; Data capacity: 200; Seamless main-standby communication switching
• Environmental Ratings: Operating temperature: -20°C to +60°C; Storage temperature: -25°C to +70°C; Relative humidity: 5%-95% (non-condensing); Front panel protection class: IP54; Resistant to electromagnetic interference
• Mechanical & Installation: Lightweight and portable design; Housing material: Black plastic; Dimensions (approx.): 38×34×223 mm; Comfortable grip for free movement in the work area; Plug-and-play connection for easy assembly
• Compatibility: Fully compatible with ABB IRC5 series robot control systems; Supports software upgrades for future function expansion
• Certifications & Compliance: Complies with industrial safety standards; Equipped with CE3T-10R-02 emergency stop button meeting safety specifications; Passes strict reliability and EMC testing
