Introduction to ABB O3ES HENF445789R1
HENF445789R1 Product Overview
The ABB O3ES HENF445789R1 is a high-performance industrial automation control module, specifically designed for distributed control systems (DCS), robotic systems, and large servo control systems. As a key product in ABB’s O3ES series, it integrates comprehensive signal processing, precise process control, and multi-protocol communication capabilities, serving as a core component for industrial data acquisition, equipment control, and real-time monitoring. The module supports seamless integration with various field devices and upper-level control systems, enabling efficient data exchange and accurate control of industrial processes such as temperature, pressure, and flow. Featuring a rugged and modular design, it exhibits excellent stability and anti-interference performance, ensuring reliable operation in harsh industrial environments like power plants, chemical factories, and steel mills.
HENF445789R1 Technical Specifications
-
Product Model: O3ES HENF445789R1
-
Product Type: Industrial Automation Control Module
-
Core Functions: Industrial process control, real-time data acquisition & analysis, multi-protocol communication adaptation, sensor signal conversion, remote device monitoring & control, fault diagnosis & alarm, channel isolation protection
-
Power Supply: 24 V DC or 220 V AC input; Built-in voltage stabilization and surge protection; Typical power consumption: ≤ 8 VA
-
Input/Output Specifications: Supports 4-20 mA analog input/output, 0-10 V DC signal; 16-channel configurable digital I/O ports; Channel isolation: ≥ 2500 VAC; Output load capacity: ≤ 500 Ω (analog), ≤ 2 A (digital)
-
Communication Protocols: Supports EtherCAT, PROFINET, Modbus RTU, Ethernet/IP; Dual Ethernet ports for redundant communication to ensure data stability
-
Response Performance: Signal response time ≤ 8 ms; Conversion accuracy: ±0.1% FS; Equipped with 32-bit RISC processor (100 MHz clock frequency) for fast data processing
-
Environmental Ratings: Operating temperature: -20°C to +60°C; Storage temperature: -40°C to +85°C; Protection class: IP30 (IP67 optional for harsh environments); Relative humidity: 5%-95% (non-condensing)
-
Mechanical & Installation: Compact modular design (approx. 100×100×40 mm); Weight: approx. 0.5 kg; DIN rail/panel-mounted; LED status indicators for real-time operation monitoring; Supports hot-swapping and modular expansion
-
Compatibility: Fully compatible with ABB DCS/PLC systems; Seamless integration with ABB O3 series modules and industrial automation equipment
-
Certifications & Protection: CE, UL certified; Overcurrent, overvoltage and short-circuit protection; Complies with IEC 61131-2 industrial control standards
Recommended ABB Same-Series Models
-
ABB O3ED: Industrial control module with multi-signal processing, suitable for basic process control and equipment monitoring
-
ABB O3EGb HENF315118R2: Multi-protocol control module, supporting dual Ethernet redundant communication for diverse system integration
-
ABB O3EHa HENF315087R2: Analog input control module with HART support, specialized in high-precision sensor signal acquisition
-
ABB O3EC HENF442581R1: Configurable I/O control module, adapting to multi-type signal processing needs in DCS
-
ABB O3EX HENF315845R2: High-performance industrial module, with 16 digital I/O ports and multi-protocol communication
-
ABB O3EId HENF452777R3: Control module with high-precision optical sensing, supporting multiple industrial communication interfaces
-
ABB E3EP HENF315276R1: Programmable logic controller (PLC) with expandable I/O, for industrial process control
-
ABB E3ED: Industrial process control module with built-in PLC functions, suitable for precise parameter regulation
-
ABB O3EC HENF442582R1: Industrial control module with extended I/O channels, for large-scale process monitoring
-
ABB O3EHa HENF315088R2: Enhanced analog input module with extended channels, supporting multi-sensor signal collection
-
ABB E3EFa HENF452750R1: Controller module with multi-type I/O, supporting cloud-based real-time data collaboration
-
ABB AC500-eCo V3: Compact PLC module with Ethernet ports, compatible with IoT protocols for smart factories
-
ABB INPM01: Process monitoring module, enabling real-time collection and analysis of industrial parameters
-
ABB INPD01: High-precision data acquisition module, focusing on analog and digital signal processing
-
ABB O3ES HENF445790R1: Enhanced industrial automation module with extended communication protocols, for complex robotic control
