Introduction to ABB UFC911B108 3BHE037864R0108
3BHE037864R0108 Product Overview
The ABB UFC911B108 (order code: 3BHE037864R0108) is a compact and high-performance digital I/O control module belonging to ABB’s UFC911 series, specifically engineered for industrial automation, DCS distributed control systems, and precision equipment control scenarios. Featuring 8 configurable digital I/O channels, it integrates high-speed signal processing and programmable logic control capabilities, enabling real-time acquisition of sensor status and precise driving of field actuators. Widely applied in CNC machining centers, semiconductor manufacturing equipment, and small-scale production lines, it ensures millisecond-level response to control signals, improving equipment coordination efficiency and reducing production errors. Equipped with built-in overload and short-circuit protection, it effectively avoids module damage caused by abnormal working conditions, while its compact design (80mm×45mm×22mm) facilitates installation in space-constrained control cabinets. Compatible with Modbus TCP protocol and supporting RS485 and Ethernet communication interfaces, it seamlessly connects to ABB’s AC 800M DCS and third-party controllers, realizing centralized monitoring and remote parameter adjustment.
3BHE037864R0108 Technical Specifications
-
Product Model: UFC911B108 (Order Code: 3BHE037864R0108)
-
Product Type: Compact digital I/O control module
-
Series Affiliation: ABB UFC911 Industrial Control Module Series
-
Core Functions: Digital signal acquisition, field device control, overload protection, high-speed data transmission
-
I/O Configuration: 8 configurable digital I/O channels (24VDC, PNP/NPN selectable)
-
Electrical Ratings: Rated voltage 24VDC; Rated current 10A (module total); Output current 1A per channel
-
Response Performance: Input response time ≤0.2ms; Output switching time ≤0.3ms
-
Protection Features: Overload protection, short-circuit protection, reverse polarity protection
-
Communication Interface: 1×Ethernet port, 1×RS485 port; Supports Modbus TCP protocol
-
Environmental Adaptability: Operating temperature -25°C to +55°C; Storage temperature -40°C to +70°C; Humidity 5-95% (non-condensing)
-
Mechanical Features: 80mm×45mm×22mm (L×W×H); Weight ~150g; DIN rail mount; LED status indicators
-
Protection Rating: IP20 (cabinet-mounted); Vibration resistance 5g; Shock resistance 30g
-
Power Supply: 24VDC ±10%; Power consumption ≤5W
-
Certifications: CE, UL certified; Compliant with industrial control safety standards
Recommended ABB Products
-
ABB UFC911B106 3BHE037864R0106: A higher-channel hybrid control module (16 I/O channels) that pairs with the UFC911B108 in large-scale control systems.
-
ABB PM864AK01 3BSE018161R1: AC 800M CPU module that processes the I/O data collected by the UFC911B108 for centralized control.
-
ABB XVC724BE101 3BHE009017R0101: High-precision analog input module that complements the UFC911B108 for mixed-signal acquisition systems.
-
ABB CI854A 3BSE022363R1: Communication module that expands the UFC911B108’s connectivity to Profibus DP networks.
-
ABB REF615 1MRK504153-BEN: Protection relay that uses the UFC911B108’s status signals to trigger over-limit safety actions.
-
ABB PPD113B03-26-100110 3BHE023584R2634: High-integration digital I/O module that extends the UFC911B108’s channel capacity in large production lines.
-
ABB DSQC1032: Analog I/O module that pairs with the UFC911B108 to collect continuous signals from pressure and temperature sensors.
-
ABB 5SHX1445H0001 3BHL000391P0101: IGCT module that works with the UFC911B108 in high-power drive systems for status feedback.
-
ABB XO08R2 1SBP260109R1001: Compact digital output module that enhances the UFC911B108’s driving capacity for small actuators.
-
ABB PS860 3BSE008545R1: Redundant power supply module that ensures stable 24VDC input for the UFC911B108 in critical applications.
