Product Description:
The GE DS200LPPAG1AAA is a Power Conditioning Module designed for use within GE’s Mark V series gas/steam turbine control systems. Its primary function is to receive incoming AC power, condition it (including filtering and transient protection), and distribute stable, protected AC power to other critical boards and components within the Mark V I/O pack enclosure.
Product Parameters / Specifications (DS200LPPAG1AAA):
|
Feature
|
Specification / Description
|
|---|---|
|
Manufacturer
|
GE Energy / GE Industrial Systems
|
|
Series
|
Mark V Turbine Control System
|
|
Part Number
|
DS200LPPAG1AAA
|
|
Part Type
|
Power Conditioning Module / Board Assembly
|
|
Primary Function
|
AC Power Conditioning & Distribution
|
|
Input Voltage (Typ.)
|
Designed for standard AC supply within the Mark V I/O pack (e.g., 120VAC, common input range 90-140VAC or similar – Verify specific system voltage)
|
|
Output(s)
|
Conditioned & Protected AC Power to internal boards
|
|
Protection Features
|
Fuses, Transient Voltage Suppression (TVS) / Surge Protection
|
|
Mounting Location
|
Installed within the Mark V I/O Pack enclosure
|
|
Key Components
|
Fuse holders, MOVs (Metal Oxide Varistors) or other TVS devices, terminal blocks, wiring harness connectors
|
|
Critical Role
|
Provides clean, protected power critical for reliable operation of Mark V I/O pack electronics.
|
Key Features:
- AC Power Conditioning: Filters incoming AC power to reduce noise and disturbances.
- Transient Protection: Incorporates protective devices (like MOVs) to suppress voltage spikes and surges, safeguarding downstream sensitive electronics.
- Power Distribution: Serves as a central hub for distributing AC power to various modules within the I/O pack (e.g., relay boards, communication boards).
- Fused Protection: Includes fuses to protect power distribution branches against overcurrent events.
- Enclosure Integration: Designed specifically for physical mounting and electrical interconnection within the Mark V I/O Pack assembly.
- Redundancy Support (System Level): Part of a control system architecture often designed with redundant power paths for high availability.
Primary Function & Purpose:
The core purpose of the DS200LPPAG1AAA is to ensure the clean, stable, and protected delivery of AC power to all the electronic modules housed within a Mark V I/O pack. It acts as the first line of defense against power line disturbances that could damage sensitive control circuitry or cause malfunctions.
Typical Applications & Use Cases:
The DS200LPPAG1AAA module is exclusively used within the context of GE Mark V gas turbine or steam turbine control systems. Its applications include:
- Gas Turbine Power Plants: Control systems for power generation.
- Steam Turbine Power Plants: Control systems for power generation.
- Combined Cycle Power Plants: Integrating gas and steam turbine control.
- Industrial Turbine Applications: Driving compressors, pumps, etc.
- Marine Propulsion: Control systems for marine gas turbines.
Application Field:
This module is a critical component in the Industrial Automation and Control Systems (IACS) sector, specifically within the niche of large-scale turbine control and protection for power generation and heavy industrial applications. It falls under the category of critical power distribution and protection hardware for industrial control cabinets (I/O Packs).
