GE Electric | IS200AEPCH1BAA | Excitation processor card
IS200AEPCH1BAA Product Overview
Functional Description:
The GE IS200AEPCH1BAA is an Advanced Excitation Processor card within GE’s Mark VI Speedtronic™ turbine control system. It regulates generator field current, maintains terminal voltage stability, and implements protection logic for synchronous generators in power plants and industrial facilities.
Key Parameters & Specifications
|
Parameter
|
Specification
|
|---|---|
|
Part Number
|
IS200AEPCH1BAA
|
|
Series
|
GE Mark VI Turbine Control System
|
|
Function
|
Generator Excitation Control & Protection
|
|
Input Voltage
|
48 V DC (±10%) via backplane
|
|
Communication
|
Dual 100 Mbps Ethernet + PROFIBUS DP
|
|
I/O Interface
|
32-bit PCI bus (for EX2100 I/O packs)
|
|
Processor
|
PowerPC 603e @ 200 MHz
|
|
Memory
|
32 MB SDRAM, 16 MB Flash
|
|
Operating Temp.
|
-30°C to +65°C (-22°F to +149°F)
|
|
Protection Functions
|
Over-excitation, Under-voltage, V/Hz Limiter
|
|
Firmware
|
Compatible with ToolboxST™ v7.0+
|
|
Certifications
|
UL 508, CE, IEEE 421.4, RoHS
|
Product Series
- Core component of GE’s Mark VI platform (legacy system), designed for gas/steam turbine generator control.
Key Features
- Dual-Channel Redundancy: Auto-failover < 100 ms
- Adaptive PID Control: Voltage regulation ±0.5%
- Real-Time Diagnostics: Monitors thyristor bridges, field grounds
- HMI Integration: Supports CIMPLICITY® HMI data logging
- Cyber Security: Password-protected firmware access
- Hot-Swappable: Tool-less replacement during operation
Functions & Roles
- Automatic Voltage Regulation (AVR): Maintains generator output voltage.
- Power System Stabilizer (PSS): Damps grid frequency oscillations.
- Field Current Limiting: Prevents rotor overheating.
- Protection Tripping: Activates on loss-of-synchronism or over-fluxing.
- Black Start Capability: Self-excitation during grid restoration.
Applications & Use Cases
|
Industry
|
Application
|
|---|---|
|
Thermal Power
|
Gas/Steam Turbine Generator Excitation
|
|
Hydroelectric
|
Brushless Exciter Control
|
|
Industrial
|
Synchronous Motors in Compressors/Pumps
|
|
Marine
|
Shipboard Power Generation
|
|
Cogeneration
|
Combined Heat & Power (CHP) Plants
|
Documentation & Support
- Manual: GEH-6421D (Mark VI Excitation Systems)
- Software: GE ToolboxST™ (v7.0+)
- Compatibility: Interfaces with EX2100 excitation cabinets
- Lifecycle Status: Active Production (GE P/N: PVB793205T)
- Legacy Note: Replaces older AEP-105 exciter controllers
Critical Specifications:
- Field Power Requirement: 125 V DC (isolated) for thyristor firing
- Typical Response Time: < 20 ms for voltage deviations
- Harmonic Distortion: < 1.5% THD at full load
