GE IS200JPDFG2AED Product Introduction
1. Product Description
The GE IS200JPDFG2AED is a 125V DC power distribution board under the GE Mark VIe series. It serves as a key element in industrial control setups, enabling the distribution of power within complex systems. Its design allows for the creation of customized engineered solutions suitable for a wide array of critical industrial applications.
2. Product Parameters
|
Parameter
|
Details
|
|
Input Voltage
|
Redundant 125V DC inputs
|
|
Power Distribution
|
Distributes power to other system boards
|
|
DC Bus Type
|
Floating DC bus centered on earth
|
|
Hazard Rating
|
Non – hazardous live 125 VDD rating
|
3. Product Specifications
- Physical Dimensions: Compact design to fit into standard industrial enclosures, though specific dimensions might vary based on the overall system requirements.
- Mounting Method: Features a secure mounting mechanism, which could be DIN – rail mounting or panel – mount, ensuring stable installation in various industrial settings.
- Environmental Conditions: Engineered to operate in harsh industrial environments. It can function within a temperature range, typically from – 20°C to + 60°C. Additionally, it has good resistance to humidity, vibration, and electromagnetic interference.
- Electrical Isolation: Incorporates high – quality electrical isolation techniques to prevent electrical interference between different parts of the control system and protect the board from voltage surges.
4. Series
It belongs to the GE Mark VIe series. Products in this series are renowned for their high reliability, performance, and compatibility within GE’s broader industrial automation and control ecosystems. They are designed to meet the stringent demands of industrial applications, especially in power generation, industrial machinery, and other heavy – industry sectors.
5. Features
- Redundant Power Inputs: Accepts redundant 125V DC power inputs, enhancing system reliability. In case one power source fails, the board can continue to function using the other input.
- Floating DC Bus: Operates with a floating DC bus centered on earth instead of a traditional ground system. This design allows for the detection of system ground faults, adding an extra layer of safety and diagnostic capabilities.
- Non – Hazardous Rating: Carries a non – hazardous live 125 VDD rating, ensuring safe operation in industrial environments.
- High – Speed, Networked I/O: Supports high – speed data transfer and networked input/output operations, enabling quick communication with other components in the control system.
- Versatile System Support: Compatible with simplex, dual, and triple modular redundant (TMR) systems, providing flexibility in system design.
- Industry – Standard Ethernet Connections: Equipped with industry – standard Ethernet connections, facilitating seamless integration with other network – enabled devices and systems.
6. Function
The primary function of the IS200JPDFG2AED is to take in redundant 125V DC power inputs and distribute this power to other system boards within an industrial control system. Its floating DC bus design helps in detecting ground faults, and it provides a non – hazardous power source for connected components. By supporting high – speed I/O and having standard Ethernet connections, it also plays a role in enabling efficient communication between different parts of the control system.
7. Use
In an industrial control system, the IS200JPDFG2AED is used to ensure a stable and reliable power supply to various components. It can be used in power – critical applications where redundant power sources are necessary to prevent system failures. For example, it can supply power to control boards, sensors, and actuators within a turbine control system, ensuring that these components receive the necessary power even in the event of a power source disruption.
8. Application Fields
- Power Generation: Widely used in power plants, including gas turbine, steam turbine, and hydroelectric power generation facilities. In gas turbine power plants, it can power the control systems that manage the combustion process, fuel flow, and turbine speed. In steam turbine power plants, it ensures a stable power supply to components that monitor and control steam flow, pressure, and temperature.
- Industrial Manufacturing: Applied in industrial facilities where turbines are used for mechanical drive applications. For instance, in large – scale manufacturing plants where turbines drive compressors, pumps, or other industrial machinery, the IS200JPDFG2AED provides a reliable power source to the control systems of these turbines, ensuring the smooth operation of the manufacturing process.
- Oil and Gas Industry: Used in oil and gas production facilities. Turbines in these facilities are used for various purposes such as powering compressors for gas transportation or driving pumps for oil extraction. The IS200JPDFG2AED can power the control systems that monitor and control these turbines, allowing for accurate operation in the harsh environment of the oil and gas industry.
