GE IS420UCSBH4A Dual port Ethernet switching module
1. Product Description
The GE IS420UCSBH4A is a Dual-Port Ethernet Switch Module designed for Mark VIe gas/steam turbine control systems. It provides high-reliability, redundant communication between controllers, I/O packs, and HMI interfaces within GE’s Speedtronic™ platform.
2. Product Parameters & Specifications
Key Specifications Table
|
Category
|
Specification
|
|---|---|
|
Part Number
|
|
|
Series
|
Mark VIe Turbine Control System (UCSB Series)
|
|
Type
|
Industrial Ethernet Switch Module
|
|
Ports
|
8x 10/100Base-TX Copper Ports + 2x 100Base-FX Fiber Ports
|
|
Switching Capacity
|
3.2 Gbps
|
|
Protocols
|
Ethernet/IP, MODBUS TCP, PROFINET, SRTP, DLR
|
|
Redundancy
|
PRP/HSR (Parallel Redundancy Protocol / High-availability Seamless Redundancy)
|
|
Power Supply
|
24V DC (18–32V range) via terminal block
|
|
Operating Temp
|
-40°C to +70°C (-40°F to +158°F)
|
|
Certifications
|
UL 508, CE, IEC 61800-5-1 (SIL 2 capable)
|
|
MTBF
|
>500,000 hours
|
|
Dimensions
|
145 x 110 x 40 mm (5.7 x 4.3 x 1.6 in)
|
3. Series & Variants
- Series: Part of GE’s Mark VIe UCSB (Universal Control Switch Blade) Series.
- Variant Notes:
- H4A suffix denotes enhanced redundancy (PRP/HSR) and fiber-optic support.
- Predecessor: IS420UCSBH1A (no fiber ports).
- Compatible with Mark VIe Controllers (e.g., IS200/IS215 series).
4. Key Features
- Dual-Homing Redundancy: Zero-loss failover via PRP/HSR for critical networks.
- Fiber-Optic Isolation: Eliminates electrical noise in harsh environments.
- Deterministic Traffic: Prioritizes control system data (QoS).
- Hot-Swappable: Supports replacement without system shutdown.
- Diagnostics: Port-level LEDs, SNMP monitoring, and event logging.
- Cyber Security: MAC address filtering, VLAN support, and port security.
5. Function & Role
- Network Backbone: Connects Mark VIe controllers, I/O packs (e.g., IS220PDIAH1A), and workstations.
- Data Aggregation: Consolidates turbine control, protection, and monitoring data.
- Redundancy Management: Ensures uninterrupted communication during faults.
- Protocol Translation: Bridges legacy systems (e.g., MODBUS RTU) to Ethernet.
6. Applications & Use Cases
Primary Application Domain
Power Generation Turbine Control Networks:
|
Application
|
Function
|
|---|---|
|
Controller Interconnect
|
Links redundant Mark VIe controllers (TMR architecture).
|
|
I/O Integration
|
Connects distributed I/O packs across turbine skid.
|
|
HMI/SCADA Integration
|
Interfaces with operator workstations (CIMPLICITY, iFIX).
|
|
Remote Monitoring
|
Enables data exchange with plant DCS/PLC systems.
|
Secondary Industrial Uses
- Oil & Gas compressor control
- Hydroelectric plant networks
- Marine propulsion control systems
7. Comparison to Previous Versions
|
Feature
|
IS420UCSBH4A
|
IS420UCSBH1A
|
|---|---|---|
|
Fiber Ports
|
2x 100Base-FX
|
None
|
|
Redundancy
|
PRP/HSR
|
RSTP only
|
|
SIL Certification
|
SIL 2 capable
|
SIL 1
|
|
Environmental
|
-40°C to +70°C
|
-20°C to +60°C
|
Summary
The GE IS420UCSBH4A is a mission-critical Ethernet switch for Mark VIe turbine control systems, delivering fault-tolerant networking with industrial-grade robustness. Its dual fiber/copper ports and PRP/HSR redundancy ensure millisecond-level failover, crucial for power generation safety and reliability.
⚠️ Note: Requires configuration via ToolboxST™ software. Compatible with Mark VIe controllers (v08.20+ firmware). For lifecycle support, contact GE Power Conversion Services.
System Integration Diagram
Turbine Sensors → I/O Packs (IS220PDIAH1A) → **IS420UCSBH4A** ↔ Mark VIe Controller ↔ HMI
↑
Redundant UCSBH4A
