The GE PCIE-5565PIORC-100000 is a high-performance industrial PCI Express (PCIe) communication module, belonging to GE’s reflective memory product family. As a core component for industrial automation and distributed processing systems, it is specifically designed to enable real-time data sharing, high-speed communication and seamless integration between industrial devices, controllers and control systems. It is widely applied in manufacturing, energy, aerospace simulation, industrial testing and other fields, serving as a bridge between legacy systems and modern digital infrastructures to enhance system scalability and real-time performance.
Technical Parameters & Specifications
|
Item
|
Specifications
|
|---|---|
|
Product Model
|
PCIE-5565PIORC-100000
|
|
Product Type
|
Industrial PCIe Communication Module, Reflective Memory Series
|
|
Manufacturer
|
General Electric (GE)
|
|
Form Factor
|
Low Profile PCI Express (PCIe) x4 Card
|
|
Power Supply
|
12-24 VDC ±10%, suitable for unstable industrial power environments
|
|
Operating Temperature
|
-40°C to +70°C (-40°F to +158°F), adaptable to harsh industrial working conditions
|
|
Storage Temperature
|
-40°C to +85°C (-40°F to +185°F), ensuring stable storage in extreme temperature conditions
|
|
Relative Humidity
|
5% – 95% (non-condensing), effectively preventing moisture damage to internal components
|
|
Onboard Memory
|
128MB SDRAM (expandable to 256MB), for high-speed data buffering and storage
|
|
Data Transfer Rate
|
Up to 2 Gb/s; sustained fiber optic bandwidth: 43MB/s to 170MB/s
|
|
Communication Interfaces
|
1 transmit + 1 receive fiber optic ports (LC connector); supports Ethernet, Modbus, CANopen, Profibus protocols
|
|
Fiber Optic Specifications
|
Multi-mode fiber: up to 300m; Single-mode fiber: up to 10km; Serial connection speed: 2.125GHz
|
|
Mounting Type
|
PCI Express slot mounting, compatible with standard industrial computer chassis
|
|
Certifications
|
CE, RoHS compliant, meeting international industrial safety and environmental standards
|
|
Compatibility
|
Supports Windows XP/Vista/Win7/Win10, VxWorks, Linux, RTx; compatible with GE reflective memory systems and ToolboxST software
|
Product Features
The GE PCIE-5565PIORC-100000 integrates high-speed performance, high reliability and flexible compatibility, perfectly meeting the core needs of industrial real-time communication and data sharing:
1. High-Speed Real-Time Communication: Equipped with PCIe x4 interface and 2.125GHz fiber optic network, it achieves low-latency data transmission (450-500 nanoseconds between nodes) and high bandwidth, ensuring real-time data sharing between multiple devices.
2. High Reliability: Adopts industrial-grade components and conformal coating protection, with strong anti-electromagnetic interference (EMI) and surge suppression capabilities, ensuring long-term stable operation in harsh industrial environments.
3. Flexible Compatibility: Supports multiple industrial communication protocols and operating systems, seamlessly integrating with legacy systems and modern digital infrastructures, eliminating the need for multiple interface cards.
4. Efficient Data Processing: With onboard SDRAM and independent DMA channel, the fiber optic communication protocol does not occupy CPU resources, realizing efficient data buffering and transmission without affecting system performance.
5. Easy Installation & Maintenance: Low-profile PCIe form factor, easy to install in standard industrial computer chassis; supports hot-swap functionality, allowing maintenance or replacement without system shutdown, reducing industrial downtime.
Other GE Similar Models
In addition to the GE PCIE-5565PIORC-100000, GE provides a series of high-quality reflective memory and industrial communication modules to adapt to different application scenarios:
1. GE PCIE-5565RC: A standard PCIe reflective memory module, with the same high-speed performance, suitable for scenarios requiring standard PCIe form factor.
2. GE PCI-5565PIORC: A PCI (64-bit) reflective memory module, compatible with legacy PCI bus systems, ensuring seamless upgrade of old industrial equipment.
3. GE PMC-5565PIORC: A PMC bus reflective memory module, compatible with PMC bus structure, suitable for aerospace, industrial testing and other professional fields.
4. GE IS215ACLEH1A: An analog I/O control module, perfectly matching the PCIE-5565PIORC-100000 to realize high-precision signal collection and output in industrial automation systems.
