Bently Nevada 3500/20 125744-02 Product Overview
3500/20 125744-02 Product Introduction
Bently Nevada 3500/20 125744-02 is a standard Rack Interface Module (RIM) designed exclusively for the Bently Nevada 3500 machinery protection and condition monitoring system. Serving as the core communication and configuration hub of the entire rack system, this module establishes unified data interaction channels between internal rack modules and external monitoring software. It supports system configuration uploading and downloading, real-time status reporting, and basic network data transmission, enabling centralized management of all monitoring units in the rack. Adopting industrial-grade circuit design, it ensures stable and continuous operation in complex industrial environments. As a mandatory core component for normal operation of the 3500 series rack, it lays a solid foundation for reliable machinery condition monitoring and fault early warning.
3500/20 125744-02 Technical Specifications
-
Product Model: 3500/20, Part Number 125744-02 (Standard Rack Interface Module)
-
Core Function: Rack system management, module configuration, and unified data transmission
-
Communication Port: Onboard RS232 serial communication interface
-
Baud Rate: Supports 38.4k baud high-speed serial data transmission
-
Power Consumption: Typical power consumption of 4.75W for low-energy operation
-
Installation Rule: Installed in the first slot of 3500 system rack as the core management unit
-
Operating Temperature: -30°C to +65°C, adaptable to standard industrial cabinet environments
-
Storage Temperature: -40°C to +85°C for safe offline storage
-
Humidity Resistance: Tolerates up to 95% non-condensing relative humidity
-
System Compatibility: Fully compatible with all modules of Bently Nevada 3500 series rack systems
Recommended Bently Nevada Same-Series Models
-
3500/15: Redundant power supply module providing stable and reliable power for system racks
-
3500/22: Transient data interface module for high-speed waveform acquisition and network transmission
-
3500/25: Dual-channel Keyphasor module for shaft phase reference and rotational timing signal collection
-
3500/40M: Multi-functional monitoring module for vibration and axial displacement measurement
-
3500/42M: Enhanced vibration monitoring module for high-precision mechanical fault analysis
-
3500/50: Speed monitoring module for real-time rotation speed detection and overspeed protection
-
3500/53: Multi-point temperature acquisition module for tracking equipment thermal operating status
-
3500/32: Relay output module for on-site alarm output and equipment protection interlock
-
3500/60: Remote communication gateway module for long-distance system data interaction
-
146031-01: High-performance data transmission module supporting efficient system networking
