The GE IS200WETCH1A is a high-reliability top box module C board assembly, belonging to GE Mark VIe Wind Turbine Control Series. As a critical electronic component for wind power generation systems, it is specifically designed to control and monitor the operating status of wind turbines, including data acquisition, signal processing, control command output and fault diagnosis. It is widely applied in GE Mark VIe series wind turbine control systems, featuring conformal coating, modular design and strong compatibility to ensure stable and efficient operation of wind power systems in harsh outdoor environments[6].
Technical Parameters & Specifications
|
Item
|
Specifications
|
|---|---|
|
Product Model
|
IS200WETCH1A
|
|
Product Type
|
Top Box Module C Board Assembly, GE Mark VIe Wind Turbine Series
|
|
Manufacturer
|
General Electric (GE), GE Energy
|
|
Functional Acronym
|
WETC; Functional Revision: 1A
|
|
Power Supply
|
24V DC (±10%), compatible with GE Mark VIe wind turbine power system
|
|
Hardware Configuration
|
4 fuses (2 center-mounted, 2 corner-mounted), 1 transformer, 2 terminal strips (6 positions each), 44 voltage regulators, 2 inductor coils, multiple integrated circuits, resistors, diodes and capacitors[4]
|
|
Connectivity
|
Over 40 plugs and jacks (primarily female), located on the edge of the PCB for efficient connectivity; exposed copper band around the board edge
|
|
Operating Temperature
|
-40°C to +70°C (-40°F to +158°F), adaptable to harsh outdoor wind power environments
|
|
Storage Temperature
|
-40°C to +85°C (-40°F to +185°F), ensuring stable storage in extreme temperature conditions
|
|
Relative Humidity
|
5% – 95% (non-condensing), preventing moisture damage to internal components
|
|
Protection Coating
|
Conformal coating, enhancing anti-corrosion and anti-moisture performance for outdoor operation
|
|
Protection Rating
|
IP54 (IEC 60529), dustproof and waterproof, suitable for outdoor wind turbine cabinet installation
|
|
Mounting Type
|
PCB board mounting, compatible with GE Mark VIe wind turbine control cabinet backplanes
|
|
Dimensions (L×W×H)
|
Approx. 180mm × 150mm × 25mm, compact design for space-saving installation in wind turbine control boxes
|
|
Net Weight
|
Approx. 0.8kg, lightweight design facilitating installation and transportation
|
|
Compatibility
|
Perfectly compatible with GE Mark VIe wind turbine control systems and ToolboxST software; compatible with other Mark VIe series modules
|
|
Certifications
|
CE, RoHS compliant, meeting international industrial safety and environmental standards for wind power equipment
|
|
Additional Features
|
Voltage suppression and resistance design; marked with manufacturer logo and ID number; functional revision A-rated; supports fault diagnosis and real-time data transmission
|
GE IS200WETCH1A
Product Features
The GE IS200WETCH1A integrates high reliability, stable performance and easy maintenance, perfectly meeting the core needs of wind turbine control systems:
1. High Reliability for Harsh Environments: Equipped with conformal coating and IP54 protection rating, it resists moisture, dust and corrosion, ensuring long-term stable operation in outdoor wind power scenarios.
2. Comprehensive Functionality: Serves as a top box module C assembly, responsible for data acquisition, signal processing, control output and fault diagnosis, supporting efficient wind energy capture and conversion.
3. Optimized Hardware Design: Integrated with 4 fuses, voltage regulators, inductor coils and other components for voltage protection and storage; edge-mounted plugs and jacks ensure efficient connectivity.
4. Strong Compatibility: Seamlessly compatible with GE Mark VIe wind turbine control systems and matching software, facilitating system integration and upgrade without additional adaptation.
5. Easy Installation & Maintenance: Modular PCB design, compact size and standard mounting, enabling quick installation and replacement; clear marking facilitates daily inspection and troubleshooting.
Other GE Similar Models
In addition to the GE IS200WETCH1A, GE provides a series of high-quality wind turbine control modules and matching components for Mark VIe systems:
1. GE IS200WETAH1A: A wind turbine control board of the same series, with consistent performance and compatibility, suitable for different wind turbine models and control requirements.
2. GE IS200WETBH1B: A top box B module, matching the IS200WETCH1A to realize comprehensive wind turbine control and signal processing.
3. GE IS200STAIH2ACB: An analog I/O module, compatible with Mark VIe series, providing precise signal collection and output for wind turbine control systems.
4. GE IS200ERBPG1A: A wind turbine control auxiliary module, cooperating with IS200WETCH1A to enhance system stability and fault handling capability.
