Bently Nevada 330180-50-00 Product Overview
330180-50-00 Product Introduction
Bently Nevada 330180-50-00 is a standard 3300 XL 8mm Proximitor transducer designed for industrial non-contact machinery monitoring systems. As a core signal conditioning unit in the proximity measurement chain, it pairs with 8mm proximity probes to convert tiny shaft gap variations into linear analog voltage signals. The unit delivers stable and repeatable measurement outputs for radial vibration, shaft displacement and position monitoring of rotating equipment. Featuring compact structure, flexible mounting options and excellent electromagnetic compatibility, it performs reliably in noisy industrial environments. Fully compliant with API 670 industry standards, it serves as a foundational sensing component for turbines, compressors and other critical rotating machinery in energy and process industries, supporting real-time condition monitoring and predictive maintenance.
330180-50-00 Technical Specifications
-
Product Model: 330180-50-00 (3300 XL 8mm Standard Proximitor Transducer)
-
Matched Sensor: Compatible with full series of 3300 XL 8mm proximity probes and extension cables
-
Standard Sensitivity: 7.87 V/mm linear output for accurate gap conversion
-
Frequency Response: 0 Hz to 10 kHz wide bandwidth for static and dynamic signal acquisition
-
Power Supply: -17.5 VDC to -26 VDC operating voltage with 12mA maximum current consumption
-
Operating Temperature: -40°C to +85°C for general industrial cabinet and field deployment
-
Humidity Resistance: 5%–95% non-condensing relative humidity working range
-
Mounting Method: Supports DIN rail and panel mounting for flexible installation
-
Measurement Performance: Low temperature drift and high linearity for long-term stable measurement
-
Industry Compliance: Meets API 670 standard for machinery protection system requirements
Recommended Bently Nevada Same-Series Models
-
330104 Series: Standard 8mm proximity probes for general industrial vibration and position measurement
-
330105 Series: Compact reverse-install probes for narrow and confined mounting spaces
-
330106 Series: Armored proximity probes with enhanced mechanical durability for harsh field conditions
-
330780-50-00: 11mm Proximitor transducer for large gap range industrial measurement scenarios
-
330850 Series: High-temperature resistant Proximitor units for extreme thermal working environments
-
330500 Series: Velomitor sensors for mechanical casing vibration velocity monitoring
-
3500/40M: Multi-functional monitoring module for processing vibration and displacement sensor signals
-
3500/42M: Seismic monitoring module for mechanical vibration fault analysis and early warning
-
3500/45: Position monitoring module for collecting shaft displacement and expansion data
-
3500/22: Transient data module for capturing high-speed equipment waveform data
